SK Collet
Characteristic
Model : SK
SK collet is a high-speed precision collet, often used in the high degree of balance, precision precision CNC machineCollet
Collet chuck Runout-Max μ (A:0.005mm)(AA:0.003mm)
~If you need AA level, please inform us clearly.~
TYPE | Round d | D | L | Weight(kg) |
SK06- | 3 3.175 3.5 4 4.5 5 5.5 6 | 10.0 | 25.0 | 0.01 |
SK10- | 3 3.175 3.5 4 4.5 5 5.5 6 6.5 7 7.5 8 8.5 9 9.5 10 | 16.0 | 30.0 | 0.02 |
SK13- | 3 3.175 3.5 4 4.5 5 5.5 6 6.5 7 7.5 8 8.5 9 9.5 10 11 12 13 | 20.0 | 39.0 | 0.04 |
SK16- | 3 3.175 3.5 4 4.5 5 5.5 6 6.5 7 7.5 8 8.5 9 9.5 10 11 12 13 14 15 16 | 24.5 | 45.0 | 0.08 |
SK20- | 6 8 10 12 14 16 18 20 | 29.3 | 50.0 | 0.14 |
SK25- | 6 8 10 12 14 16 18 20 25 | 35.0 | 57.0 | 0.24 |
